Pultruded CFRP Carbon Fibre I Bracket For Position
What is pultruded carbon fiber?
Continuous fibers or continuous fiber products are drawn by a certain composition of the traction device, and the guide device is turned to the glue tank and the preform mold mixed with the curing agent and resin, and the mold with the heating temperature control device is fixed and solidified, and finally formed continuous composite profile products.
Tasuns Carbon fibre I/U/L shaped angle bracket:
| Regular size(U channel) | ||
| Size(mm) | Unit Weight(kg/m) | |
| 25*12*3.0 | 0.258 | |
| 30*15*3.0 | 0.324 | |
| 32*18*4.0 | 0.48 | |
| 47*23*5.0 | 0.83 | |
| 50*25*4.0 | 0.736 | |
| 65*30*4.0 | 0.936 | |
| 68*32*4.2 | 1.04 | |
| 100*35*5.0 | 1.6 | |
| 103*38*6.0 | 2.0 | |
| customized | customized | |
| Regular size(I Channel) | ||
| Size(mm) | Unit Weight(kg/m) | |
| 20*15*3.0 | 0.294 | |
| 23*26*3.5 | 0.455 | |
| 25*30*4.0 | 0.576 | |
| 45*32*5.0 | 1.12 | |
| 50*35*5.0 | 1.25 | |
| 60*46*9.0 | 2.66 | |
| 75*55*12 | 4.34 | |
| 80*30*3.2 | 0.84 | |
| customized | customized | |
| Regular size(L Channel) | ||
| Size(mm) | Unit Weight(kg/m) | |
| 20*20*3.0 | 0.29 | |
| 25*25*3.0 | 0.28 | |
| 30*30*3.5 | 0.39 | |
| 35*35*4.0 | 0.53 | |
| 50*50*5.0 | 0.95 | |
| 70*70*6.0 | 1.61 | |
| 75*75*6.0 | 1.73 | |
| 90*90*8.0 | 2.75 | |
| customized | customized | |
Size checking:
Tolerance: +/- 0.1mm
Packaging:
1)packing each by bubble wrap;
2) carton box
|
|
